Poly Solar Panel 5-280W TUV,IEC,CEC,CE,ISO HSPV-250W-156-66P manufacturer from China Shandong Hi-light Solar CO.LTD

Poly Solar Panel 5-280W TUV,IEC,CEC,CE,ISO

Price:	0.62~0.82 USD
Payment Terms:	T/T,L/C,D/A,D/P,WU
Place of Origin:	Shandong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: HSPV-250W-156-66P

Production Capacity: 10MW/Month

Delivery Date: 15days

Type: Others

Place of Origin: Shandong, China (Mainland)

Material: Polycrystalline Silicon

Number of Cells: 66PCS

Maximum system voltage: 1000VDC

Tolerance: ±3%

Means of Transport: Ocean,Air

Packing: Carton,Pallet

Application: Others

Brand Name: Hilight Solar

Model Number: HSPV-250Wp-156-66P

Size: 1790*992*45mm

Max. Power: Solar Panel 260W

Permissible temperature: -40℃ To +85℃

Solar Panel 5w-280w
1).IEC,CE,ISO,TUV
2).25 years of service life
3).Widely used,easy installation

250WPoly Solar panel with CE TUV IEC:

Polycrystalline Solar Panel 250-280W, Passed TUV, CEC, IEC, CE, INMETRO and ISO authentication

1.TUVstandard flash test

1) Flash testmachine with TUV standard reference solar panel,all Propsolar Panel is testedunder 100%TUV standard flash test or standard higher than TUVstandard.

2)In themarket,not all solar panel is real tested with TUV standard,Flash machinereference panel is not TUV standard,so the power is 2%-3% less than TUVstandard

2.Characteristics

1)High efficiency crystalline silicon solar cells

2)Manufactured according to international standard and EnvironmentManagement

System(ISO9001, ISO14001)

3)3.2mmthick tempered glass, strong mechanical resistance

4)Anti-ageingEVA and excellent anti-climate back sheet

5)Anodizedaluminum frame improves load resistance capabilities for heavy windloads.

6)Standardwaterproof junction box

7)Highendurance to different weather

8)Goodand friendly package with less transportation and storage space.

3.Transferrable power outup Warranty

1)10years limited manufacturing warranty

2)12years for 90% of warranted minimum power

3)25years for 80% of warranted minimum power

4.Electricalparameters

Skype:hilightsales13 Tel:(+86)15153290678

PolySolar Panel Datasheet
Poly Solar PanelModel	Power(Wp)	Solar CellArray	Size: MM ( L x W xH)	Vmp(V)	Imp (A)	Voc (V)	Isc (A)	Certificates
HSPV250Wp-156-66P	250 Wp	66PCS(6X11)	1790x992x45	32.80	7.62	39.60	8.42	CE,TUV,CEC
HSPV255Wp-156-66P	255 Wp	66PCS(6X11)	1790x992x45	32.90	7.75	39.70	8.56	CE,TUV,CEC
HSPV260Wp-156-66P	260 Wp	66PCS(6X11)	1790x992x45	33.00	7.88	39.80	8.60	CE,TUV,CEC
HSPV260Wp-156-72P	260 Wp	72PCS(6X12)	1956x992x50	35.30	7.37	43.00	8.06	CE,TUV,CEC
HSPV265Wp-156-72P	265 Wp	72PCS(6X12)	1956x992x50	35.40	7.49	43.20	8.18	CE,TUV,CEC
HSPV270Wp-156-72P	270 Wp	72PCS(6X12)	1956x992x50	35.50	7.61	43.20	8.33	CE,TUV,CEC
HSPV275Wp-156-72P	275 Wp	72PCS(6X12)	1956x992x50	35.60	7.72	44.20	8.48	CE,TUV,CEC
HSPV280Wp-156-72P	280 Wp	72PCS(6X12)	1956x992x50	35.70	7.84	44.30	8.62	CE,TUV,CEC
Power ProductionTolerance: ± 3%				Maximum SystemVoltage: DC 1000V
Temperature coefficients of Isc (%):+0.1/°C				Temperature coefficients of Voc (%): -0.38/°C
Temperature coefficients of Pm(%) : -0.47/°C				Temperature coefficients of Im (%): +0.1/°C
Temperature coefficients of Vm (%): -0.38/°C				Temperature Range : -40°C~+80°C
Max. Wind Load / Max SnowLoad: 2400 Pa/5400 Pa				Standard Test Conditions :Irrandiance 1000W/M2,Moduletemperature25°C,AM=1.5
Warranty :10 years 90% power output, 20 years 80% of power,25years lifetime
